2004
Year
AMELS
Builder
170' 8" (52.02m)
Length
5
Cabins

NITA K II 2004 170' 8" AMELS Motor Yacht

Palm Beach United States $23,900,000 USD

The 2004 170' 8" AMELS 2004 Displacement Motor Yacht NITA K II is a yacht for sale located in Palm Beach, Florida, United States.



Contact the yacht broker to receive more information or schedule a showing of this 2004 170' 8" AMELS 2004 Motor Yacht Displacement NITA K II yacht for sale in Palm Beach, Florida, USA today!
Get more information on this listing
John Cohen Merle Wood & Associates, Inc.
Call Email
LENGTH 170' 8" (52.02m)
BUILDER AMELS
ASKING PRICE $23,900,000 USD
BUILT (REFIT) 2004 (2021)
BEAM 29' 5" (8.97m)
DRAFT N/A
MAX SPEED 15 Knots
CRUISING SPEED 12 Knots
CABINS 5
GROSS TONNAGE 628.00
DISPLACEMENT N/A
LOCATION Palm Beach, Florida, USA
Get more information on this listing
John Cohen
Merle Wood & Associates, Inc.
Call Email

Full Specifications

Additional specifications are available for this listing. Click below to get detailed information.


CONSTRUCTION

Steel hull, aluminum superstructure, teak decks

DIMENSIONS

General
Length Overall (L.O.A.):        170.61 feet             (52.00 meters)
Beam (molded):    29.60 feet             (  9.00 meters)
Draft (loaded):    10.00 feet             (  3.05 meters)
Tonnage:   628 gross tons; 188 net tons; 653 displacement tons

Capacities
Fuel Capacity:  31,176 US Gallons  (118,000 liters)
Water Capacity:               4,755 US Gallons  (  17,997 liters)
Watermakers:  (2) @ 4,808 US Gallons  (  18,200 liters)
Lube Oil:  557 US Gallons  (    2,110 liters)
Waste Oil:  520 US Gallons  (    1,970 liters)
Waste Water:  1,442 US Gallons  (    5,460 liters)

  Speed  Consumption per hours  Range  RPM
Maximum:  15.0 knots  400 liters/hr  3,200 NM  385
Cruising:   12.5 knots  280 liters/hr   3,950 NM   325
Economical:        11.0 knots  220 liters/hr   5,000 NM   290

MACHINERY

Main Engines
Engine Type:
  • (2) Cummins KTA 38-M2 diesels @ 1,200 Hp each
Gearboxes for Main Engines:
  • Reintjes WAF 542 Ratio: 4.45:1
Drive:
  • Lips Fixed pitch propellers

Generators & Electricity


Generators:
  • (2) 145 kW Kilo Pak generators (New July 2014)

  • (1)   40 kW Cummins 4B 3.9 emergency generator
Generator Fuel Consumption:
  • 192 liters/day per unit
Shore Power:
  • (2) 62.5 KVA Atlas shorepower SPA 3 Phase
Output volts 400 output amps:
  • 230/400/50 Hz
Input Volt:
  • Atlas shore power conversion system
Batteries:
  • Main engine start: air; charged: compressors

  • Generator start: 24V batteries charged Mastervolt charger

Air Conditioning
Type:
  • Marine Air – 38 Air handlers

Other Machinery
Watermakers:
  • (1) Watermaker Inc. WMSQ-45000

  • (1) Watermaker Inc. WMSQ-3000
Stabilizers:
  • Koopnautic SR3575/4080 SVA (At Anchor)
Bow Thruster:
  • HRP 200-60E 110 kW Hp
Steering System:
  • Rolls Royce/Tenjford JR 2.160 ram type
Fuel Separator & Filtration:
  • Alfa Laval MIB 303
Sewage System:
  • Headhunter
Helm/Control Stations:
  • (3) Located bridge/Port wing station/Stbd wing station

  • Completely rewired and new control (July 2014)

COMMUNICATION, NAVIGATION & ENTERTAINMENT SYSTEMS

Communication Systems
VSAT:
  • Seatel VSAT
SATcom:
  • Nera Fleet 77, data, speed 128k
Telephone System:
  • Panasonic
SSB:
  • Sailor 6301 MF/HF
VHF Fixed:
  • (1) Furuno FM8800S DSC-VHF

  • (1) Sailor RT4822 VHF-DSC
VHF Handheld:
  • (2) Icom IC-M87
Cellular Phone System:
  • (3) + Globesurfer
Intercom:
  • Panasonic
Internal Ship’s Communication:
  • Phontech
Hattera Screens:
  • (1) 22” Touch screen, (4) 19” screens
Furuno Sat C
  • (1) new 2017 with Furuno printer

Navigation Systems
Radar:
  • (1) Furuno 2110 X-Band; Range 120 nm
  • (1) Furuno 2110 S-Band; Range 120 nm
Gyrocompass:
  • (1) C-Plath Navigat MK1  (new Nov 2015)
Magnetic Compass:
  • (1) C-Plath
Auto Pilot:
  • (1) C-Plath Navipilot V HSC
Depth Sounder:
  • (1) Furuno ED2200 wing station repeaters
Video Sounder:
  • (2) Furuno FCV-585 with (2) transducers fwd and (1) aft
GPS:
  • (2) Simrad MX 612
Ships Computer:
  • (2) Nav PC Custom; (4) HP PC; (1) HP PC
IT Server:
  • (3) New servers and complete new state of the art IT/WIFI throughout vessel
Printers:
  • (4) HP
Chart Plotter:
  • (1) Transas Navi-Sailor 4000 New September 2017
Chart Plotter:
  • (1) Maxsea  new September 2017
Wind Indicator:
  • (1) Thomas Walker (relative) + Furuno RD-30 weather station
Speed Indicator:
  • (1) C-Plath Naviknot III speed log
Navtex:
  • (1) Furuno NX-500
AIS:
  • (1) Furuno FA-150 universal

Entertainment System:
Central Ship’s Audio:
  • Complete new A/V throughout vessel e.g. Central system includes a Kaleidescape server linked to a new RTI control system.  In addition there are new Mini iPads throughout the vessel for controlling the  A/V and music server in addition to public areas (Party Mode), Apple TV, airplay.
    All lower Guest cabins A/V systems are in two individual racks with dual SAT TV/DVD/Kaleidescape
    (Complete new AV system July 2014)
    All apple tv devices are new july 2017

Audio/Video Equipment

TV’s:
  • (2) KVH HD 11 TV antenna’s (new 2016)
  • (1) Samsung Flatscreen 26’ – Captain cabin (multisystem)
  • (12) Samsung  22’ LCD/DVD – 6 Crew cabins (multisystem)
  • (1) Samsung 50” curve – Crew mess
  • (1) Samsung 85” – Skylounge
  • (1) Samsung65” – Main salon
  • (1) Samsung 55” – Master cabin
  • (1) Samsung 55” Master office
  • (2) Samsung 42” – Guest cabins
  • (2) Samsung 33” – Guest cabins
  • (1) Marantz – Crew mess
  • (1) Marantz – Skylounge (new 2017)
  • (4) Marantz – Guest cabins


STEREOS:
  • (1) Marantz – Skylounge
  • (1) Marantz – Master cabin
  • (1) Marantz – Main salon


I-POD STATIONS:
  • (2) Bridge

GALLEY & LAUNDRY EQUIPMENT

Main Galley Equipment
Cooking
  • (1) Schott 4-burner range
  • (1) Gaggenau D38-3000 oven
  • (1) Panasonic NE-C145 microwave
Refrigeration/Freezer:
  • (2) Metos MMC 600 refrigerators
Dishwasher:
  • Hobart FP 70
Other:
  • Scotsman AC45 icemakers
  • (1) Dumbwaiter located galley/pantry/Sundeck
General Galley:
  • Built in deep fryer, built in grill, Kitchen Aid mixer,
    Hans Dampf Combi steamer 6.23, Paco Jet ice cream maker

Crew Galley/Mess Equipment
Cooking Equipment:
  • (1) Severin 900 microwave
Refrigeration/Freezer:
  • Indesit
Other:
  • (1) Liebherr 4177 wine cooler
  • (1) Miele 67856 dishwasher
  • (1) Uson Marine AB trash compactor

Additional Galley Equipment
Cooking Equipment:
Refrigeration/Freezer:
  • Fridina BV built in walk-in 2.7m2 refrigerator
  • Fridina BV built in walk-in 1.65m2 freezer
Other:
  • (1) Ice machine main deck aft

Laundry Equipment
Main Laundry Equipment:
  • (3) Sanuzzi Lindo 100  dryers
  • (3) Sanuzzi lindo 300 Washers
  • (1) Laura Star steam iron system

TENDERS & TOYS

Tenders:
  • (1) Novorania 24ft with diesel Volvo Inboard
Dive Gear:
  • (1) Bauer C2E dive compressor
  • (2) Yamaha Delux 3 seater waverunners 2016
  • (1) Freestyle 26ft slide
  • (2) Inflatable paddleboards
  • (2) Inflatable canoe
  • (2) Seabob F5
  • (2) towable chariots

DECK EQUIPMENT

Anchor Windlass System:
  • Steen, single motor horizontal axis
Aft Warping Capstans:
  • (4) Steen; (2) Fwd and (2) Aft
Anchors:
  • (2) Pool
Anchor Chain:
  • 22mm X 630’ (192m)
Boat Crane and Davits:
  • (2) Vandriel (1 fwd, 1 aft) – 2000 kg capacity
Accommodation Ladders:
  • Stbd side electric-hydraulic
Stern Boarding Gangway:
  • Aljo Yacht equipment, electric-hydraulic
Spotlights:
  • (1) Carlisle & Finch 83506
Jacuzzi:
  • Located on Sundeck for 6-8 people

SECURITY, FIRE FIGHTING & SAFETY EQUIPMENT

Security Equipment:
CCTV System:
  • DIVIS Palladium Technologies (New 2014)
Cameras:
  • (12) Engine room, Port/Stbd side decks, Aft deck, Mast, Bridge deck fwd and aft
Monitors:
  • (3) Radio room, Crew mess, Bridge
Deck Sensors:
  • Palladium Technologies; Three zones of deck sensors
Biometric Door Locks:
  • (2) Biometric door entrances, Guest door, Crew door
Ship’s Safe:
  • (6) Guest cabins, Master cabin, Captain’s cabin

Fire Fighting Equipment:
Fire Control System:
  • (2) Fixed CO2, engine room + galley range hood
     Various smoke detectors, (41) smoke, (5) heat, (3) gas
  • (1) Sprinkler system throughout vessel
  • (2) Asbestos firefighting suits – Viking Professional fire  fighting suits, BA locker
  • (14) Seawater firefighting stations within 15m of any point on the vessel
Portable CO2:
  • (9) Near major electrical installations
Fire Extinguishers:
  • (25) Various locations throughout vessel
Alarms:
  • All door entries are connected to the Palladium Technologies, alarm system with door sensors
Alarm Key Pad:
  • (2) Monitors, Crew door and Radio room

Safety Equipment
Life Rafts:
  • (4) RFD Surviva MKII, 16-person, Class A
Life Rings:
  • (8) Solas approved
EPIRBS:
  • (2) ACR Globalfix with built in GPS
Flares:
  • Assorted
Medical Equipment:
  • Medlink supplied and approved first aid and medical kits

ACCOMMODATIONS

Sleeps up to 12 in the owner’s party in 5 staterooms with crew accommodations for up to 14 in 7 cabins

COMMENTS

With a timeless, Dutch pedigree, NITA K II was built in 2004 by Amels, with refits in 2012, and 2016. Featuring classic exterior styling by Terence Disdale, and an exceptionally detailed interior design and decor by Alberto Pinto and Laura Sessa, generous accommodations are for 12 guests in 5 staterooms. The full-beam master stateroom offers an extensive, his-and-hers en suite, walk-in wardrobes, and an adjoining lounge or office for the ultimate in privacy.

Four spacious, king guest staterooms are below, 2 of which are VIPs that offer large, jetted tubs and oversized showers.

Expansive social areas can be enjoyed both inside, and on her outstanding, well-planned exterior decks that feature several seating, dining, and lounging options on all three outdoor levels.

NITA K II is in impeccable condition in all respects, and is cruise-ready.


    •     Stunning, custom interior design by Alberto Pinto and Laura Sessa
    •     Accommodations for up to 12 guests in 5 staterooms, including full-beam master stateroom with attached                lounge/office
    •     Crew accommodations for up to 14 in 7 cabins
    •     At-anchor stabilization
    •     [1x] 24ft RIB stored on foredeck, leaving exterior decks open for owner and guest use
    •     Full-displacement, steel hull and aluminum superstructure
    •     628 gross tons
    •     Lloyd’s classed/MCA compliant
    •     Reliable Cummins power provides max speed of 15 knots, and cruising speed of 12.5 knots with global                     cruising capabilities of 5,000 NM  @ 11 knots


- Exclusions include all of Owner's personal effects -

"All speeds, capacities, consumption, etc. are approximate or estimated; measurements can also be approximate.  Specifications are provided for information only and particulars herein obtained from sources believed to be correct, but are not guaranteed.  Buyer should instruct his agent and/or surveyor to check all details for accuracy.  Offered subject to prior sale, price and/or inventory change, or withdrawal from the market without notification."





REFIT SUMMARY 2021

  • Complete Zero Time Major overhaul of Main Engines including Gear Boxes
  • Complete Zero Time Major overhaul of Port & Starboard Generators
  • Complete Major overhaul of Stabilizers
  • Re-building of every principle pump aboard
  • Full Bottom paint & inspection of Running Gear & Bow Thruster
  • Removal & repair of Fore Deck Crane
  • Updating of NavCom equipment
  • Galley Renovation – incl. new floor, overheads, cabinet doors, new cooktop, & full service of all equipment, etc…
  • Misc exterior paint touch up & repaint of all overhead deck panels
  • Re-varnish of all cap & hand rails
  • Re-fit of aft lazzarette
  • Misc interior woodwork refinishing
  • Etc, etc, etc…
  • Above work just completed is in addition to 15 year Lloyds Survey & full exterior re-paint completed in 2019/20
