Ellen is the last of the 40m Perini Navi class and only one to have a 4 guest stateroom layout. She has been expertly maintained and has undergone a complete refit including new sails, fresh paint on masts, superstructure, hull and bottom in 2015. The bottom and internal tanks were sandblasted to bare metal and recoated at that time. New teak decks were also installed. Every system was updated with new or serviced including hydraulics, winches, HVAC, Refrigeration, NavCom and A/V. Full maintenance of the Starboard gearbox (bearings, seals, oil change, filter etc…) and regular maintenance on the Portside completed. The AC unit has been changed. Charts and Radio have been controlled and updated. All security equipment has been checked
She got a Cosmetic refit in 2020.
Additional specifications are available for this listing. Click below to get detailed information.
Ellen is a 40 m / 131′3″ luxury sailing yacht. She was built by Perini Navi in 2001. With a beam of 8 m and a draft of 6.46 m, she has a steel hull. She is powered by engines giving her a maximum speed of 13 knots and a cruising speed of 11 knots. The sailing yacht can accommodate 8 guests in 4 cabins. The yacht was designed by Perini Navi
Ellen's interior layout sleeps up to 8 guests in 4 rooms, including a master suite, 1 VIP stateroom and 2 twin cabins. She is also capable of carrying up to 6 crew onboard to ensure a relaxed luxury yacht experience. Timeless styling, beautiful furnishings and sumptuous seating feature throughout create an elegant and comfortable atmosphere.
|
BUILDER: Perini Navi YEAR: May 2001 DESIGNER: Perini Navi L.O.A: 40.4m / 132’ L.W.L: 31.72m / 104’ BEAM: 8.0m / 26’2 DRAFT: 6.37m / 22’ centreboard down (approx) 3.44m / 11’28 centreboard up (approx) DISPLACEMENT: 75 tons full load (approx) KEEL LEAD BALLAST: 30 tons SAIL AREA: Approx 812 m sq CLASSIFICATION: American Bureau of Shipping. (ABS) Malta Cross A1 & Yachting service AMS MCA |
FUEL CAPACITY: 25,000 litres
WATER CAPACITY: 8,600 litres
LUB OIL: 890 litres
GREY WATER: 1,745 litres
BLACK WATER: 1,745 litres
SLUDGE: 1,195 litres
BILGE WATER: 1,195 litres
WATERMAKER: Two Idromar Mini compact Junior 2J, 3100 litres per day each
ENGINES: Two 496hp MTU 8V 183 TE 62 (overhauled 2016)
365 Kw @ 2100rpm, 8 V90
Port ME: 9,622 H
Start ME: 9,644 H
SHORE POWER: 60 Kva shore power connection allowing use of 380v 50 Hz voltage
AIR CONDITIONING: Condaria system with fan coils in each area with treated fresh air.
GEARS: Reverse / Reduction gearbox Hundested CPG 32
Reduction ratio 3.44:1
SHAFTS & PROPELLERS: Two shafts and two four blade feathering propellers
GENERATORS: Two Northern Lights M-668T, 66 kw 380v 50 HZ
One Northern Lights 35 kw 380v 50HZ ( emergency use)
Generators overhauled 2016
Port Gen : 28,344
Start Gen : 28,316
ELECTRICITY: 380v 50 Hz three phase.
220v 50 Hz single phase.
24v DC for emergency lighting, limited energy, signaling circuit, RTF station, electronic instruments and alarms.
Bowthruster: Schottel STT-010 LK 37 Kw approx
Fuel Separator: 380V AC Alfa Laval manual MAB 103 B24 centrifugal fuel separator of approx 900 litres /hr
SAILS
Spectra sails by North new 2016. Sail monitoring system by Perini Navi
|
Genoa approx 274 m sq |
Fisherman 145 m sq |
|
Staysail 100 m sq |
Mizzen sail 111 m sq |
|
Mainsail approx 182 m sq |
MPS |
RIG
Two Perini Navi masts, in light alloy fully painted 2016, with an elliptical section with reinforcements and internal lead ways. All stainless standing and running rigging replaced in 2016.
Main Mast Four pairs of spreaders and one double jumper
Mizzen Mast Three pairs of spreaders and two single jumpers
Genoa, Main, Mizzen, Fisherman and Staysail equipped with Perini Navi electric furling system. Furling systems overhauled and restored to like new 2016
Two aluminium alloy booms, 11.6m and 9.9m approx with a topping-lift and electric auxillary winch. The sheets for the booms are controlled by automatic winches from the wheelhouse and Flybridge. Mast wiring replaced 2016.
|
One hydraulic stern gangway |
|
|
Eight Perini Navi Captive winches |
One tender launching pole with electric winch |
|
Six Antal winches |
One anchor Windlass |
|
Two Perini Navi Drum winches |
|
Navigation Equipment
|
One C. Plath JUPITER magnetic compass (dia. 180mm) |
One C. Plath NAVIGAT X MK1 gyrocompass |
|
One Electronic compass Three portable VHF’s
Dedicated computer with |
One C. Plath NAVIPILOT V/GM autopilot system with rudder angle feedback unit. Gyrocompass and electronic compass heading information input.
Master and repeater display and control units. |
Wheelhouse console
Plath control incorporating:
C.Plath NAVIGAT X gyrocompass console steering repeater.
C. Plath NAVIPLOT V/GM auto pilot control and display unit.( Master)
Tiller with double NFU Naviguide NN/EF
Three-mode steering gear interface selector switch (Auto / Manual / NFU ).
Over ride / take over button.
Analogue rudder angle indicator.
Flying Bridge
One analogue boat speed indicator.
One analogue wind speed indicator
One analogue magnified wind indicator.
One anologue depth gauge
Two FFD’s
Aft cockpit
One Hydraulically operated aft gangway
One Hydraulically operated side boarding ladder.
Galley Equipment
|
One Miele convection microwave |
Two twin coil Gaggenau hotplates |
|
One Gaggenau oven One Miele dishwasher 67856 |
One Gaggenau griddle One Hoshizaki ice maker |
Laundry Equipment
|
Two Miele washing machines WS5425 One Miele roller Iron B865E |
Two Miele dryers TS5205C |
|
One Broadcast and Closed circuit TV system |
One hi-fi system in the main saloon and dining saloon. Aft cockpit speakers. Independent HI-FI systems in the Owner’s cabin, guests cabin, crew cabins and crew mess. |
Main saloon
One Multi-standard 29” Loewe TV
One Multi-standard Aiwa with converter video recorder.
Stereo system including :
-Pioneer PD-M426 multi CD player
-Pioneer CT-W606DR cassette deck
-Pioneer YSX 808 RDS stereo receiver
Rotel RDV 995 DVD player
Panasonic sky digibox.
One Play Station 2.
Four JBL Control loud speakers.
Dining Saloon
One Multi-standard 29” Loewe TV
One Rotel DVD player
Four JBL loud speaker control.
One Infrared sensor.
One Sony Playstation
Aft Cockpit
Four Bose waterproof loud speakers.
One infrared sensor
Wheel house.
One Pioneer RDS car stereo
Two JBL SR 130 loud speakers.
Flying Bridge
Two Bose waterproof loud speakers (connected to wheel house car stereo)
One infrared sensor.
Owner’s cabin
One Multi-standard 21” Loewe TV
One Multi-standard Aiwa with converter video recorder.
One Technics SCDH 70 HI-FI system including
One Tuner
One Amplifier
One Rotel DVD player
One Cassette deck
Four JBL Controls for loud speakers (2 in bedroom, 2 in sitting room)
Twin guest cabin
One 21” Loewe TV
One Rotel DVD player
One Pioneer RDS car stereo
Two JBL SR 130 loud speakers.
Double guest cabin:
One Multi-standard 21” Loewe TV
One Rotel DVD player.
One Pioneer RDS and stereo.
Four JBL Control 1 loud speakers
Forward Guest Cabin:
One Pioneer RDS car stereo
Two JBL SR 130 loud speakers.
Galley
Two JBL SR 130 loud speakers
Crew Mess
One Technics Stereo system including cassette deck, multi CD player, tuner, Pioneer DV-525 DVD player.
Sharp 15’ LCD T.V
Captain’s and crew cabin
One Pioneer RDS car stereo
Two JBL SR 130 loud speakers.
|
CO 2 Fire fighting system in Engine room Three eight man inflatable liferafts Two life rings with luminous buoys Four line throwing rockets. B.A kit for fire fighting |
Portable fire extinguishers in accordance with Sixteen type-tested life jackets One set of signal rockets and distress flares Two life rings with attached lines. |
|
One 5.6m tender with diesel 2016 |
One 3.4m Novourania tender with 15HP outboard |
